種類
|
型式
|
負荷
|
微動開關形式
|
電纜種類/長度
|
接點
|
動作壓力
|
外殼材質
|
|
標準型 復歸式
|
FS-101
|
10A 250VAC
|
V-15-1C25
|
0.75mm2,3C/0.5 meter(米),1 meter(米)~3 meter(米)
|
1A1B
|
1.2kg
|
塑膠
|
|
FS-102
|
15A 250VAC
|
TM-1704
|
0.75mm2,3C/1 meter(米),1.5 meter(米)~2 meter(米)
|
1A1B
|
1.1kg
|
|
FS-3
|
10A 250VAC
|
V-15-1C25
|
0.75mm2,3C/0.5 meter(米),1 meter(米)~3 meter(米)
|
1A1B
|
1.2kg
|
鋁合金
|
|
FS-3S
|
15A 250VAC
|
TM-1704
|
0.75mm2,3C/1 meter(米),1 meter(米)~3 meter(米)
|
1A1B
|
1.1kg
|
|
標準式 交替式
|
FS-105
|
6A 250VAC
|
FS-105
|
0.75mm2,2C/1 meter(米),1 meter(米)~2 meter(米)
|
PUSH ON PUSH OFF
|
2kg
|
塑膠
|
|
FS-106
|
6A 250VAC
|
FS-105
|
0.75mm2,3C/1 meter(米)
|
PUSH 1A PUSH 1B
|
1.5kg
|
|
小型附 回定片
|
FS-201
|
10A 250VAC
|
V-15-1C25
|
0.5mm2,3C/1 meter(米)~3 meter(米)
|
1A1B
|
0.7kg
|
塑膠
|
|
FS-01
|
10A 250VAC
|
V-15-1C25
|
0.5mm2,3C/1 meter(米)~3 meter(米)
|
1A1B
|
0.7kg
|
|
FS-1
|
10A 250VAC
|
V-15-1C25
|
0.5mm2,3C/1 meter(米)~3 meter(米)
|
1A1B
|
0.9kg
|
鐵殼
|
|
護蓋型
|
FS-302
|
15A 250VAC
|
TM-1704
|
附電纜固定頭 不附電纜
|
1A1B
|
3.2kg
|
鋁合金
|
|
FS-304
|
15A 250VAC
|
TM-1704 * 2
|
2A2B
|
3.2kg
|
|
FS-305
|
6A 250VAC
|
FS-105
|
PUSH ON PUSH OFF
|
3.1kg
|
|
FS-306
|
6A 250VAC
|
FS-105
|
PUSH 1A PUSH 1B
|
3.5kg
|
|
FS-502
|
15A250VAC
|
TM-1704
|
1A1B
|
3.2kg
|
|
FS-504
|
15A250VAC
|
TM-1704 * 2
|
2A2B
|
3.2kg
|
|
FS-602
|
15A250VAC
|
按鈕彈簧式
|
2*1A1B
|
2.8kg
|
|
FS-702
|
15A250VAC
|
TM-1704
|
2*1A1B
|
3.2kg
|
|
大型
|
FS-402
|
15A250VAC
|
TM-1704
|
1A1B
|
3.2kg
|
|
FS-404
|
15A 250VAC
|
TM-1704 * 2
|
2A2B
|
3.2kg
|
|
FS-802
|
15A 250VAC
|
TM-1704
|
2*1A1B
|
3.2kg
|
